Rear Panel Connections
Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause permanent
damage to the unit.
S/VIDEO OUT
COMPONENT
VIDEO OUT
PROGRESSIVE
SCAN
MONITOR OUT
S-VIDEO OUT
Jack
FM Antenna Terminals
AM Antenna Terminals
SPEAKER Terminals
POWER CORD
MONITOR OUT
Jack
AUXILIARY INPUT Terminals
COMPONENTVIDEO OUT /
PROGRESSIVE SCAN (Y Pb Pr)
Terminals
Connect to a TV with Y Pb Pr
inputs.
