3
NO. ITEMS SPECIFICATIONS
1. Engine model G200PU
2. Displacement 20.1cm
3
3. Bore x stroke ø32mm x 25mm
4. Weight 990g (not including DC Ignition Unit)
5. Carburetor type WT-811
6. Ignition Battery ignition; digital control
7. Sparkplug Champion Y82
8. Rotating direction Counterclockwise (from PTO side)
9. Starting method External motor
10. Sensor gap 0.8 ~ 1.2mm (1.0mm ± 0.2mm)
11. Fuel consumption 1.0 / 9000rpm (at full throttle)
12. Noise (at 2-meter points) 98dBA (APC 15x10)
13. Battery capacity 4.8V / 1500 ~ 2700mA
SPECIFICATIONS
