7
1. Make sure to install the power switch.
2. Push the sparkplug cap all the way over the sparkplug. (use gloves)
3. Fixate the unit within the fuselage, as shown in the diagram. Do not wrap
the unit by the sponge, cloth or the like.
4. The temperature of the bottom surface (D) of the unit, in particular, will
rise. Thus, when fixating surface (D), make sure to leave sufficient space
(a gap).
The temperature of the unit may rise to as high as 70~80°C,
depending on the operating environment and conditions, but
this is not abnormal. However, make sure not to touch this part
or you could risk being burned.
DC IGNITION UNIT MOUNTING
