Installation Instructions
Horizontal Ducting Preparation
AK9228BS & AK9234BS Models Only
13. Secure blower to captive nuts on
interior back wall of liner with (8)
3/16” x 3/8” screws, (4) screws
for each bracket. Seal any gaps
around the knock-out plate by
using certified aluminum duct
tape. Plug in blower molex plug.
Horizontal ducting preparation is now
Horizontal ducting preparation is now
complete. Refer to Page 18, Step 5 to
complete. Refer to Page 18, Step 5 to
complete installation.
complete installation.

Zephyr AK9246BS Specifications

General

Color	stainless steel
Hood Type	insert
Venting Type	ducted, external
Temperature Sensor	no
Control Type	button
Delay Start	yes
Interior Light	yes
Remote Control	no
Voltage	120 volts

Weight and Dimensions

Depth	19 1/4 inches
Height	12 inches
Width	46 3/8 inches
Net Weight	64.5 pounds
