36
Monsoon I Guide d’utilisation, d’entretien et d’installation
MONSOON I
INSÉRER
CORE
Schéma de câblage
AK9228BS & AK9234BS SCHÉMA
MOTEUR
BLANC
BLEU
MARRON
GRIS
ROUGE
JAUNE
VERT
CORPS
ROUGE
JAUNE
JAUNE
JAUNE
JAUNE
TRANSFORMATEUR
CORPS
VERT
NOIR
WHITE
ACT 390 CFM - Ventilateur Max. 355 W à 3,0 A
ACT 290 CFM - Ventilateur Max. 255 W à 2,4 A

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zephyr AK9246BS and is the answer not in the manual?

Zephyr AK9246BS Specifications

General IconGeneral
Colorstainless steel
Hood Typeinsert
Venting Typeducted, external
Temperature Sensorno
Control Typebutton
Delay Startyes
Interior Lightyes
Remote Controlno
Voltage120 volts
Weight and Dimensions IconWeight and Dimensions
Depth19 1/4 inches
Height12 inches
Width46 3/8 inches
Net Weight64.5 pounds
