Controls and Components
3.3
A. Mirrors
This motorcycle is equipped with convex mirrors. A
convex mirror has a curved surface. Convex mirrors
offer a greater field of view than a similar flat mirror.
However, the greater field of view makes objects
seem further away than they really are. Care must be
used when judging the distance of objects seen in
these mirrors.
B. Key Switch/Steering Lock
For description and operation, see “Key
Switch/Steering Lock Positions”, on page 4.2.
C. Dash
For description and operation, see “
Dash Overview”,
on page 3.8.
D. Cavity for Accessory 12 Volt Socket
Location for Zero dealer-installed 12 volt accessory
socket.
E. Front Brake Fluid Reservoir
For description and operation, see “
Brakes”, on
page 6.10.
F. Right Handlebar Control
For description and operation, see “
Handlebar
Controls”, on page 3.17.
G. Front Brake Lever
For description and operation, see “
Handlebar
Controls”, on page 3.17.
H. Throttle Control
For description and operation, see“
Handlebar
Controls”, on page 3.17.
I. Motor Stop Switch
For description and operation, see “
Handlebar
Controls”, on page 3.17.
J. Tank Storage Lock
Lock for motorcycle tank bag, see “
Tank Storage
Compartment”, on page 3.23.
K. Left Handlebar Control
For description and operation, see “
Handlebar
Controls”, on page 3.17.
