182
ESSENTIAL TECHNICAL PARAMETERS
POWER
Model of the tractor
Proxima
Plus 85
Proxima
Plus 95
Proxima
Plus 105
Model of the engine 1205 1005 1305
Power on the output shaft (kW±2%)
- at nominal speed of the engine and engaged 1,000 min
-1
of
the output shaft
Not run-in engine (up to 100 Mth) 50 55 62.5
Run-in engine (from 100 Mth) 52.5 58 65.5
LIFTING FORC EOF THREE-POINT HITCH
Lifting force at the end of lower pull bars of the rear three-point
hitch within full extent of the up-stroke with maximum usable
pressure
- with one auxiliary cylinder (kN)
- With two auxiliary cylinders (kN)
34.4
41.5
Lifting force at the end of lower pull bars of the front three-point
hitch within full extent of the up-stroke with maximum usable
pressure (kN) 23
