Zhiyun CRANE - M2 S User Manual

19
How to Use CRANE-M2 S
Gimbal Modes Description
Motors circled in red are free to move in line with the movement of the gimbal
handle while motors circled in grey are locked.
横滚轴
俯仰轴
航向轴
Pan Follow mode (PF):
The tilt axis and roll axis motors are
locked, and the camera rotates with
the handle while panning horizontally.
Push the joystick up/down to control
the tilt axis angle, and push it left/right
to control the pan axis of the camera.
横滚轴
俯仰轴
航向轴
Lock mode (L):
All three motor angles are locked, and
the camera orientation will not move
with the rotation of the handle. Push
the joystick up/down to change the tilt
angle of the camera and left/right to
change the horizontal orientation of
the camera.
Tilt Axis
Pan Axis
Roll Axis
Tilt Axis
Pan Axis
Roll Axis

Zhiyun CRANE - M2 S Specifications

General

Model	CRANE-M2 S
Type	3-Axis Handheld Gimbal Stabilizer
Max Payload	720g
Weight	549g
Pan Angle Range	360°
Bluetooth	Yes
Charging Time	1 hour 41 minutes
Dimensions	240 x 68 x 150 mm
Battery Type	Built-in Li-ion
Display	OLED screen
Compatible Devices	Smartphones, Action Cameras, Compact Cameras
USB Charging	Yes (USB-C)
Follow Modes	Pan Follow, Lock, POV, Vortex, Go
Control Interface	Joystick
Battery Runtime	Up to 10.5 hours
