eZ80
®
CPU
User Manual
UM007714-0908
CPU Instruction Set
162
INC SP
Increment
Operation
SP
←
SP
+1
Description
The CPU increments the contents
of the Stack Pointer register (
SP
) by 1. In ADL mode, or
when the
.L
suffix is employed, SPL is used for
SP
. In Z80 mode,
or when the
.S
suffix is
employed, SPS is used for
SP
.
Condition Bits Affected
None.
Attributes
Mnemonic
Operand
ADL Mode
Cycle
Opcode (hex)
INC
SP
X1
33
INC.S
SP
12
52, 33
INC
.L
SP
02
49, 33
170
