UM007714-0908 CPU Instruction Set
199
LD (HL), rr
Load Indirect
Operation
(HL) ← rr
Description
The rr operand is any of the multibyte registers BC, DE, or HL. The CPU writes the con-
tents of the multibyte register
rr to the memory location specified by the contents of the
multibyte HL register.
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LD (HL),BC 0/1 4/5 ED, 0F
LD.S (HL),BC 1 5 52, ED, 0F
LD.L (HL),BC 0 6 49, ED, 0F
LD (HL),DE 0/1 4/5 ED, 1F,
LD.S (HL),DE 1 5 52, ED, 1F
LD.L (HL),DE 0 6 49, ED, 1F
LD (HL),HL 0/1 4/5 ED, 2F
LD.S (HL),HL 1 5 52, ED, 2F
LD.L (HL),HL 0 6 49, ED, 2F
