ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
204
LD ir, r
Load
Operation
ir ← r
Description
The ir operand is any of the 8-bit CPU registers IXH, IXL, IYH, or IYL. The r operand is
any of the 8-bit CPU registers A, B, C, D, or E. The CPU writes the contents of the speci-
fied register
r to the selected register ir .
Condition Bits Affected
None.
Attributes
jj identifies the A, B, C, D, or E register and is assembled into one of the opcodes indi-
cated in Table 64.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LD IXH,r X2DD, jj
LD IXL,r X2DD, kk
LD IYH,r X2FD, jj
LD IYL,r X2FD, kk
