eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
207
LD IX/Y, (IX/Y+d)
Load Index Register
Operation
IX/Y ← (IX/Y+d)
Description
The CPU writes the contents of the memory location, specified by the contents of the IX
or IY register offset by the two’s-complement displacement
d , to the multibyte Index Reg-
ister, IX or IY.
Condition Bits Affected
None.
Attributes
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LD IX,(IX+d)0/1 5/6 DD, 37, dd
LD.S IX,(IX+d)1 6 52, DD, 37, dd
LD.L IX,(IX+d)0 7 49, DD, 37, dd
LD IY,(IX+d)0/1 5/6 DD, 31, dd
LD.S IY,(IX+d)1 6 52, DD, 31, dd
LD.L IY,(IX+d)0 7 49, DD, 31, dd
LD IX,(IY+d)0/1 5/6 FD, 31, dd
LD.S IX,(IY+d)1 6 52, FD, 31, dd
LD.L IX,(IY+d)0 7 49, FD, 31, dd
LD IY,(IY+d)0/1 5/6 FD, 37, dd
LD.S IY,(IY+d)1 6 52, FD, 37, dd
LD.L IY,(IY+d)0 7 49, FD, 37, dd
