eZ80
®
CPU
User Manual
UM007714-0908
CPU Instruction Set
215
LD MB, A
Load MBASE
Operation
MBASE
←
A
Description
In ADL mode (ADL mode bit
=
1), the CPU writes the contents of the accumulator
, A, to
the MBASE register
. otherwise., no
operation occurs (two-cycle NOP).
Condition Bits Affected
None.
Attributes
Mnemonic
Operand
ADL Mode
Cycle
Opcode (hex)
LD
MB,A
X
2
ED, 6D
223
