ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
267
OTIRX
Output to I/O and Increment Memory Address with Stationary I/O Address
Operation
repeat {
{UU, DE[15:0]} ← (HL)
BC ← BC – 1
HL ← HL+ 1
} while BC ≠ 0
Description
The CPU loads the contents of the memory location specified by the multibyte HL register
into CPU memory. The CPU next loads the contents of this byte to the I/O address {UU,
DE[15:0]}. The upper byte of I/O addresses is undefined. The BC register decrements.
The HL register increments. The Z Flag is set to 1 if the BC register decrements to 0. The
instruction repeats until the BC register equals 0.
Condition Bits Affected
Attributes
This instruction is not supported on eZ80190 device.
S Not affected.
Z Set of BC – 1 = 0; reset otherwise.
H Not affected.
P/V Not affected.
N Set if msb of data is logical 1; reset otherwise.
C Not affected.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
OTIRX —X 2 + 3 *
BC
ED, C3
OTIRX.S —1 3 + 3 *
BC
52, ED, C3
OTIRX.L —0 3 + 3 *
BC
49, ED, C3
