ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
326
RST n
Restart
Operation
(SP) ← PC
PC ← {0000h,n}
Description
The RST instruction functions similar to a CALL instruction. However, the 8-bit n oper-
and is limited to 8 specific values:
00h, 08h, 10h, 18h, 20h, 28h, 30h, and 38h. After
stacking the Program Counter (and ADL mode bit, if necessary), the
RST instruction is
written the 8-bit restart vector
n to the Program Counter.
Table 92. RST N Instruction Detail
ADL Suffix Operation
0 None The starting Program Counter is {MBASE, PC[15:0]}.
Push the 2-byte return address, PC[15:0], onto the
{MBASE,SPS} stack. The ADL mode bit remains
cleared to 0. Write {00h, nn} to PC[15:0]. The ending
Program Counter is {MBASE, PC[15:0]} = {MBASE, 00h,
nn}.
1 None The starting Program Counter is PC[23:0]. Push the 3-
byte return address, PC[23:0], onto the SPL stack. The
ADL mode bit remains set to 1. Write {0000h, nn} to
PC[23:0]. The ending Program Counter is
PC[23:0] = {0000h, nn}.
0 .S The starting Program Counter is {MBASE, PC[15:0]}
Push the 2-byte return address, PC[15:0], onto the
{MBASE, SPS} stack. Push a 02h byte onto the SPL
stack, indicating an interrupt from Z80 mode (ADL = 0).
The ADL mode bit remains cleared to 0. Write {00h, nn}
to PC[15:0]. The ending Program Counter is {MBASE,
PC[15:0]} = {MBASE, 00h, nn}.
1 .S The starting Program Counter is PC[23:0]. Push the 2
LS bytes of the return address, PC[15:0], onto the
{MBASE, SPS} stack. Push the MS byte of the return
address, PC[23:16], onto the SPL stack. Push a 03h
byte onto the SPL stack, indicating an interrupt from
ADL mode, because ADL = 1. Reset ADL mode bit to 0.
Write {00h, nn} to PC[15:0]. The ending Program
Counter is {MBASE, PC[15:0]} = {MBASE, 00h, nn}.
