UM007714-0908 CPU Instruction Set
358
SUB A, ir
Subtract without Carry
Operation
A ← A – ir
Description
The ir operand is any of the 8-bit registers IXH, IXL, IYH, or IYL. The ir operand is sub-
tracted from the contents of the accumulator, A. The result is written to the accumulator.
Condition Bits Affected
Attributes
S Set if result is negative; reset otherwise.
Z Set if result is 0; reset otherwise.
H Set if borrow from bit 4; reset otherwise.
P/V Set if overflow; reset otherwise.
N Set.
C Set if borrow; reset otherwise.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
SUB A,IXH X 2 DD, 94
SUB A,IXL X 2 DD, 95
SUB A,IYH X 2 FD, 94
SUB A,IYL X 2 FD, 95
