16
Installation instructions & user manual
T210023 v1.02 NOV 2018 - ZIP AP430S-AP4100S
Technical support
Tel: 0345 6 005 005 email: service@zipindustries .co.uk www.zipwater.co.uk
Operation
• After it has been connected to the water and power supply grid, the heater is ready to be
used.
• When connected to the power supply, the heater runs in standby mode. In the standby
mode, the heater maintains the water temperature of 10°C.
• The heater is equipped with the SmartEco electronic
regulator, which enables the setting of water temperature, error
diagnostics and smart mode with which you can reduce the use
of electric energy.
Fig. 8 Control panel
Display of:
• Set temperature.
• Actual temperature of water in the heater.
• Errors.
On / Off button, temperature setting.
Indication of the SMART function.
Switch for the SMART function.
2
3
4
1
Switching the heater on / off
• The water heater can be switched on by holding the
button for 3 seconds.
• By holding the button for 3 seconds again, the
heater goes into standby.
2
2
Operating the Aquapoint - manual settings
Operating the Aquapoint
• Temperature is set by pressing button until you get the desired temperature level
(preset temperature level is 57°C).
Freeze protection temperature 10°C.
Water temperature 35°C.
Water temperature 57°C.
Water temperature 75°C.
eco
2
Note all temperature values
are nominal.
