7
INSTALLATION INSTRUCTIONS & USER MANUAL
210005 V2.00 AUG 2017 - ZIP APIII/5-15(OB)
TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
4
4
3
6&7
5
9
1
2
8
10
12
11
REF ITEM DESCRIPTION
1 AQ0330 Element
2 AQ0331 Gasket
3 AQ0332 Control knob lens
4 AQ0333 Thermostat
5 AQ0334 Resettable cut-out
6 AQ0335 Sacrificial anode 10 & 15 litre
7 AQ0347 Sacrificial anode 5 litre
8 AQ0336 Indicator light
9 AQ0337 Control knob with spring
10 AQ0338 Heating flange
11 AQ0345 Anode gasket
12 AQ0346 Insulating bush
EXP0921 Expansion relief valve (not shown)
SPARE PARTS
