Page 6 of 24 Hydro Tap Installation and Operating Instructions - 89026UK - June 2009
In addition to normal tools, the following will be required:
• 35mm diameter sheet metal hole punch for sink tops. (not supplied)
• 35mm diameter hole saw for timber bench tops. (not supplied)
• Nut runner tube spanner (supplied) for fixing tap assembly.
When installing a Font unit:
• For Font installation: a 108mm diameter sheet metal or hole saw to suit
surface being cut.
Special tools required
Domestic models covered by these instructions
Model Height mm Depth mm Width mm Weight empty kg’s Weight full kg’s
30009UK 334 320 188 9 11.5
37697UK 337 323 280 9.5 12
437677UK 348 380 385 26 30
