Zip InLine ES3 User Manual

13
INSTALLATION INSTRUCTIONS & USER MANUAL
210011 V2.02 MAY 2018 -ZIP ES
TECHNICAL SUPPORT TEL: 0345 6 005 005 EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
Typical installation
• Fig. 4 shows open vented installation.
• Fig. 5 show unvented installation with closed outlet tap.
Fig. 4
Fig. 5
Service Valve
Flow Control Valve
Mains Supply
Fit Aerator insert
Aerator insert
Rear Cable Entry
Non-return
valve
INSTALLATION

Zip InLine ES3 Specifications

General

Brand	Zip
Model	InLine ES3
Category	Water Heater
Language	English
