Zippity Baskenridge - Step 4: Assemble Gate Wings

WWW.ZIPPITY-OUTDOOR.COM
8
ASSEMBLY INSTRUCTIONS
ZP19038
STEP 4.1 STEP 4.2
STEP 3.3
Align the Gate Latch (H) with the top of the top gate rail and pre-drill
 black self-drilling
stainless steel screws.
Orient (2) Posts (C)
so the tabs are facing
up as illustrated.
Insert the posts down
through (2) Rails (B).
Align the pre-drilled
holes in the rails with
the pre-drilled holes
in the posts.
Fasten the posts
and rails together

self-drilling stainless
steel screws. Repeat
for the second gate
wing.
H
C
B
STEP 4: ASSEMBLE GATE WINGS
Tabs
Align
Align
Note: Orient the posts as illustrated
