1.3.2 INTF1 interface characteristics
P2: Optical interface with multimode (62.5 µm) fiber type
Type of connector
ST female
Wavelength
820 nm
Transmitter optical power level
(for logic level “1”)
-18 dBm/-9 dBm (Min./Max.)
Permissible optical power level
in reception
-24 dBm/-10 dBm (Min./Max.)
Approximate range
Up to 2 km
Operating mode
Selectable by internal settings from among:
➢ C37.94 with a fixed number of timeslots (1,
2 or 8) or with the number specified in the
frame itself
➢ CMI/FM0 at 64 kbit/s, 128 kbit/s, 512 kbit/s
or 2048 kbit/s
➢
Transparent 1 (up to 28800 bit/s)
➢
Transparent 2 (up to 960 kbit/s)
P1: Optical interface with single mode (9/125 µm) fiber type
Type of connector
FC female
Wavelength
1310 nm
Transmitter optical power level
(for logic level “1”)
-3.5 dBm
Permissible maximum attenuation
30 dB
Approximate range
Up to 60 km
Operating mode
Selectable by internal settings from among:
➢ C37.94 with a fixed number of timeslots (1,
2 or 8) or with the number specified in the
frame itself
➢ CMI/FM0 at 64 kbit/s, 128 kbit/s, 512 kbit/s
or 2048 kbit/s
➢
Transparent 1 (up to 28800 bit/s)
➢
Transparent 2 (up to 960 kbit/s)
