F2MUX
FAMILY OF CONVERTER DEVICES TYPE F2MUX 15/28
USER GUIDE - Rev. V00 (June 2021)
2.1 POWER-SUPPLY CONNECTION
All F2MUX versions are powered from a DC or AC supply voltage (36-300 Vdc,
38-265 Vac), through the connector shown in FIGURE 4.
The female connector supplied with the equipment is suitable for rigid or flexible conductors
of up to 2.5 mm
2
.
FIGURE 4 Location and use of the power-supply connector in the F2MUX
In DC supply-voltage operation, the equipment is protected against polarity inversion.
