FAMILY OF CONVERTER DEVICES TYPE F2MUX 12/28
USER GUIDE - Rev. V00 (June 2021)
P3: Optical interface with SFP (Small Form Factor Pluggable) bay
SFP 4CZ07980014
Type of fiber: multimode
Type of connector: LC
Wavelength: 850 nm
Approximate range: Up to 2 km
Operating mode: C37.94 standard
SFP 4CZ07980013
Type of fiber: single mode
Type of connector: LC
Wavelength: 1310 nm
Approximate range: Up to 40 km
Operating mode: C37.94 standard
P4: Optical interface with multimode (62.5 µm) fiber type
Type of connector
ST female
Wavelength
820 nm
Transmitter optical power level
(for logic level “1”)
-18 dBm/-9 dBm (Min./Max.)
Permissible optical power level
in reception
-24 dBm/-10 dBm (Min./Max.)
Approximate range
Up to 2 km
Operating mode
C37.94 standard
1.3.4 Mechanical characteristics
Dimensions
19” (483 mm) wide and 1 s.u. high (44 mm).
Depth of 170 mm (with connectors).
See FIGURE 3
Approximate weight
2 kg
Fixing
By four 6.5 mm diameter holes
