ZIV F2MUX - Technical Characteristics; General Characteristics

F2MUX
FAMILY OF CONVERTER DEVICES TYPE F2MUX 9/28
USER GUIDE - Rev. V00 (June 2021)
1.3 TECHNICAL CHARACTERISTICS
1.3.1 General characteristics
Operating principle
The F2MUX is able to convert and optical fiber
interface into an electrical interface or optical
with a different protocol and/or connector
Available F2MUX versions
F2MUX.10: Multimode (ST) optical into
electrical G.703 at 2 Mbit/s conversion
F2MUX.11: Multimode (ST) optical into
electrical G.703 at 64 kbit/s conversion
F2MUX.12: Multimode (ST) optical into C37.94
optical conversion (SFP bay)
F2MUX.13: Multimode (ST) optical into
multimode (ST) C37.94 optical conversion
F2MUX.20: Single mode (FC) optical into
electrical G.703 at 2 Mbit/s conversion
F2MUX.21: Single mode (FC) optical into
electrical G.703 at 64 kbit/s conversion
F2MUX.22: Single mode (FC) optical into
C37.94 optical conversion (SFP bay)
F2MUX.23: Single mode (FC) optical into
multimode (ST) C37.94 optical conversion
Test devices
➢ Loop in INTF2 interface
➢
Test in INTF1 and INTF2 interfaces
Optical indications
➢ Terminal powered on
➢ Activity in INTF1 interface
➢ Activity in INTF2 interface
➢ Equipment in loop/test
➢ Alarm in INTF2 interface
Standard
IEC TS 61000-6-5
