3.Device Installation
Install on the wall
1 2
43
1.5m
Baseline
1
2
①
②
③
④
Attach the mounting template sticker to the wall, and drill holes according to
the mounting paper.
Secure the back plate on the wall with the wall mounting screws.
After passing the wires through the wiring hole and connecting them to the
device, and then attach the device to the back plate from top to bottom.
Fasten the device to the back plate with a security screw.
Note: The installation method of KF1200 is the same as that of KF1100. Only
KF1100 is used as an example, and will not be repeated here again.
3
