STATE
PWR
EXT
RS485
PC
RS485
SWITCH
BEEP
GLED
WD1
WD0
GND
+12V
READER1
7.InBio Connection
6.Power Connection
Minimum :12V, 1.5A, :AC adapter AC adapter , . Recommended 12V 3A
Use an AC adapter with a higher current rating to share power with the
other devices.
AC Adapter
DC12V
InBio Series
GND
GND
+12V
+12V
WD2
WD1
GND
BEEP
LED-R
LED-G
ALARM
GND
485A
485B
5
