ZKTeco KF1000 Series Quick Start Guide

8.DM10 Connection
WD2
WD1
GND
BEEP
LED-R
LED-G
ALARM
GND
485A
485B
GND
485A
485B
Note:
1. You need to manually enable the DM10 function on the WebServer to access.
The path: [Advanced Settings] > [Serial Comm] > [Serial Port] > [Dm10].
2. A KF1000 series only supports connecting one DM10.
3. Set the 485 address of DM10 to 1.
4. Each device requires a separate power supply.
5. For more details, please refer to the User Manual.
DM10
+12V DC
6
1 2
3
4
485 Address
