11 Ethernet Connection
Connect the device and the system over an Ethernet cable. An example is shown below:
: 192.168.1.201Default IP Address
: 255.255.255.0 Subnet mask
: 192.168.1.130IP Address
: 255.255.255.0 Subnet mask
Note: In LAN, IP Addresses of the server (PC) and the device must be in the same network segment
when connecting to the ZKBioSecurity MTD software.
Click [Comm.] > [Ethernet] > [IP Address], input the IP address and click on [OK].
10 Power Connection
Recommended power supply: 12V - 3A
To share the power with other devices, use a power supply with higher current ratings.
12V 3A DC
8
