X Series User’s Manual Chapter 2 Installation & Operation
Figure 3
1. Printhead Module 2. Printhead Holder 3. Printhead
4. Reflective Media Sensor 5. Transmissive Media Sensor 6. Printhead Latch Levers
7. Media Guide 8. Ribbon release lever 9. Ribbon Supply Compartment
10. Media Compartment 11. Ribbon Supply Wheel 12. Platen Roller
2
1
3
4
12
6
7
8
9
10
11
5
8
6
7
