X Series User’s Manual Chapter 1 Introduction
Chapter 1 Introduction
Specifications
Specifications for Printer
Model X1 X1i
Printing method Direct thermal & Thermal transfer
Resolution 203 DPI (8 dots/mm) 300 DPI (11.8 dots/mm)
Maximum print speed 6 IPS(152.4 mm/s) 4 IPS(101.6 mm/s)
Maximum print width 4.09″(104 mm) 4.15″ (105.6 mm)
Maximum print length
157.5″（4000mm） 78.7″（2000mm）
Memory 2 MB FLASH ROM, 8 MB SDRAM
Media Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal
paper
Width：4.5″（114 mm） max.,0.8″（20 mm）min.
Supply roll: OD 5″(127 mm) max., ID 1″(25.4 mm) min.
Thickness: 0.08～0.20mm(0.003″～0.0078″), including liner
Ribbon Wax, Wax/Resin, Resin
Ribbon roll: OD 2.75″(70 mm) max. with ID 1″(25.4 mm) core or ID 0.5″(12.7
mm) core
Max width: 110 mm; Max length: 300 M
Media sensor Adjustable reflective & Transmissive
Bar Code Types
1D Barcode : Code 39，Code 93，Code 128，Codabar，EAN-8/13/128，Interleave
2 of 5，UCC-128，UPC A/E 2 and 5 add-on, etc.
2D Barcode : Data Matrix, MaxiCode, PDF417,QR, etc.
Interfaces RS-232 serial, USB
Power rating* 24 VDC, 2.5 A
Weight 2.62 KGS
Dimensions W208 x D310 x H195 mm
Operation
environment
Temperature: 32° F ~ +104° F (0° C ~ 40° C)
Relative humidity: 5% - 85% non condensing
Storage environment
Temperature: -40° F ~ +140° F (-40° C ~ 60° C)
Relative humidity: 5% - 85% non condensing
Optional items Peeler kit, Internal 100/10 M Ethernet Interface card
