Nomenclatura
4
10
1
2
3
5
6
7
8
9
11
12
13
14
15
16
Ref. CODE BEZEICHNUNG MENGERif. CODICE DENOMINAZIONE QUANTITÁ
1 W70291 Corpo 1
2 W69721 Piede flessibile 1
3 W83300 Disco 1
4 W56525 Tubo di uscita interna 1
5 W81710 Membrana 1
6 W81600 Anello di sostegno 1
7 W70293 Tubo di uscita esterna 1
8 W74000 Anello di compressione 1
9 W70401 Carter della membrana 1
10 W69720 Deflettore 1
11 W41710 Adattatore del tubo 1
12 W70335 Dispositivo di controllo
del flusso 1
13 W69657 Adattatore conico 1
14 W60055 Valvola automatica di 1
regolazione del flusso
15 W83353 Contrappeso 1
16 W69130 6 Tubi da 1 metro 2
