Montaggio
4 3
QUESTO APPARECCHIO VIENE CONSEGNATO
COMPLETAMENTE MONTATO :
VI RESTA SEMPLICEMENTE DA FISSARE
1
Il disco, con il lato con il marchio "Top" verso l'alto, sul piede flessibile
Questo disco deve essere correttamente posizionato nella gola del
piede flessibile e deve potere girare liberamente
(Schema A).
2
Il deflettore di forma circolare piccolo disponibile, tramite l’adattatore
del tubo come indicato sullo schema quì di fronte
(Schema B).
Schema A
Schema B
Adattatore di tudo
(Lato femmina)
Tubo di uscita
esterno
Deflettore di
forma circolare
