2.2.2 Sensor and injec on point installa on
• There must be at least 60 linear cm between the sensor and the injec on point. If this is not possible, use
the POD kit available as an op on or a check valve.
• Fixture collars (or the POD kit) must be installed on rigid Ø50 PVC pipes. A Ø63 adapter is available as an
op on.
• The POD kit is recommended if a Redox (chlorine) regula on module has also been installed.
• Maximum pressure must not exceed 1.5 bar.
• Drill a hole with a diameter between 16 and 22 mm on the pipe at the selected loca ons for the pH sensor
and the injec on point.
• Then install the xture collars.
• Use Tefl on tape to make sure the threads on the sensor holder, the injec on valve and its adapter are
water ght.
• Screw down the one or more sensor holders onto the xture collar or a POD kit (op onal),
• Carefully unscrew the protec on tube from the sensor,
• Rinse the end of the sensor with tap water and shake o excess water,
• Screw the sensor into the sensor holder, holding the BLUE connector in one hand and the black connector
in the other to avoid tangling the cable,
• Once the sensor is installed, it can be connected to the BNC connector's control box,
