Zodiac PX50 - English

6
CONTENTS
❶ Installaon 7
1.1 I Selecng the locaon 7
1.2 I Hydraulic connecons 8
1.3 I Accessing the electrical terminal blocks 9
1.4 I Power supply connecons 9
1.5 I Opon connecons 10
❷ Use 11
2.1 I Operang principle 11
2.2 I User interface presentaon 12
2.3 I Operaon 13
2.4 I User funcons 14
❸ Maintenance 16
3.1 I Winterising 16
3.2 I Maintenance 16
❹ Troubleshoong 20
4.1 I Appliance behaviour 20
4.2 I Error code display 21
4.3 I Wiring diagrams 23
❺ Specicaons 24
5.1 I Descripon 24
5.2 I Technical specicaons 25
5.3 I Dimensions and marking 26
Tip: to make it easier to contact your retailer
• Write down your retailer's contact details to help you nd them more easily and ll in the "product"
informaon on the back of the manual; your retailer will ask you for this informaon.
• Before handling the appliance, it is vital that you read this installaon and user manual, as
well as the "Warranes" booklet delivered with the appliance. Failure to do so may result in
material damage or serious or fatal injury and will void the warranty.
• Keep and pass on these documents for later viewing throughout the appliance's service life.
• The distribuon or modicaon of this document in any way is prohibited, without prior
authorisaon from Zodiac®.
• Zodiac® is constantly developing its products to improve their quality. The informaon
contained herein may therefore be modied without noce.
EN
