Zodiac T3 User Manual

Page 7
ENGLISH
Owner’s Manual
|
Zodiac
®
T3
®
Pool Cleaner
Connect the Wheel Deflector Ring
The wheel deflector ring pivots on the hose to help
directtheT3aroundstepsandotherobstacles
in the pool.
Attachthewheeldeflectorringassemblytotheend
of the last Twist-Lock hose cuff.
Connect the Cleaner
WARNING
To avoid serious injury, turn off the suction pump for the cleaner before performing this step.
1. Submerge the cleaner and flood it with
water.
2. When bubbles stop coming out of the cleaner,
connect the hose to the cleaner by pushing the
wheel deflector assembly C-clip onto the outer
extension pipe until it locks into position with a
clicking sound.
3. Allowthecleanertodrifttothebottomofthe
pool. Turn on the pool pump to begin cleaning.
Installation is complete.

Zodiac T3 Specifications

General

Pool Type	In-ground
Warranty	2 years
Pool Surface	Concrete, tile, vinyl, fiberglass
Cleaning Coverage	Floor and walls
Power Source	Pool Filtration System
Weight	18.5 lbs
Type	Suction-side pool cleaner
