Zodiac T3 User Manual

Page 8
ENGLISH
Zodiac
®
T3
®
Pool Cleaner
|
Owner’s Manual
Operation and Maintenance
Fine Tuning Cleaner Performance
TheT3cycleson/offwiththepoolfiltrationpumpvacuumingandcleaningallsurfacesrandomlythroughoutthe
pool. The coverage of the cleaner is dependent on the pool’s shape and available water flow. In some pools,
adjustments may be necessary to optimize cleaning coverage.
Incorrect
Correct
Balance
Incorrect
Properly Balanced Hose
Aproperlybalancedhosewillcreatea45ºangleto
the cleaner and the bottom of the pool.
Inpools8½ft.(2.5m)ordeeper,anextrahose
weight(part#W83247)maybenecessary.Attach
theextraweight5-8ft.(1.5-2.5m)fromthe
cleaner.
Return Line Installed
Areturnlinecanbeusedtoguidethecleaner
away from steps or areas with V-shaped
corners, and reduce patterning.
Direct the return line to gently push the cleaner
hose by positioning the return directional eyeball
so it aims towards the wall on the opposite side
ofthepool.Adjustuntilsurfacemovementis
visible8ft.(2.5m)outfromthereturn.
In this example, any return within the grey area
can be used.
Routine Maintenance
To maintain performance:
• Nevercoilthehose.Straightencoiledorkinkedhoseswithwarmwaterorbylayinghosesstraightinthesun
for several hours until heated, then reshape manually. A kinked or coiled hose will adversely affect the
cleaner’s coverage of the pool.
• Whenthecleanerisnotinthepool,keepthediscflattoavoidwarping.
• Periodicallyinspectcleanerpartsforwear.Replacethefootpadwhenthedepthsofthechannelsbetween
thetreadsare1/16in.(1.6mm)orless.
• Thoroughlycleantheskimmerbasket,pumpbasketandfilterregularly.
• Alwaysdisconnectthecleanerfromthepoolwallorskimmerbeforecleaningorbackwashingthepoolfilter.
Aftercleaningorbackwashing,letthefiltrationsystemrunforatleastfive(5)minutesbeforere-connecting
the cleaner.

Zodiac T3 Specifications

General

Pool Type	In-ground
Warranty	2 years
Pool Surface	Concrete, tile, vinyl, fiberglass
Cleaning Coverage	Floor and walls
Power Source	Pool Filtration System
Weight	18.5 lbs
Type	Suction-side pool cleaner
