Zodiac T3 - Storage and Winterizing

Page 11
ENGLISH
Owner’s Manual
|
Zodiac
®
T3
®
Pool Cleaner
3. Threadtheouterextensiontubeontothecup
assembly and tighten (see Figure 11).
4. Verifythethrustwasherisstillinplaceinside
the handnut. Insert the engine into cleaner body,
slide the handnut over the engine extension tube
and tighten (see Figure 12).
5. Make sure the extension tube
swivelsfreelybyspinningit(seeFigure13).
Storage and Winterizing
Nevercoilthehose.StoretheT3cleaneroutofdirectsunlight.Whenstoringforthewinter,drainallwaterfrom
thecleaner.Removeallconnectorsandadaptersfromthededicatedsuctionlineorskimmer.Storethediscflat,
and hose sections disconnected, drained and straight.
Figure 11
Figure13
Figure 12
