Lifter 75
9.2 LIFTER COMPONENTS AND CONTROLS
The vehicle is equipped witch two lifters – narrow, for right tailgate, and wide, for left tailgate.
Fig. 9.1 Tailgates with lifters
The container is hung on a lifters comb / and after being lifted it is held by a clamping
bar / . The flap / should be closed when emptying containers. This prevents
spilling and increases operator safety. If the flap is not closed, the automatic cycle blockade is
activated for safety reasons. The open flap collides with the raised lifter.
When opening the flap, do not hold handles on the tailgates, as there is a risk of injury.
