Preventive Maintenance Test
9650-0308-01 Rev. A ZOLL AED Plus Service Manual 1–7
Turn off the AED Plus unit.
Set the analyzer to NSR (normal sinus rhythm).
2.5 Turn on the AED Plus unit.
! UNIT OK
! ADULT PADS
! DON’T TOUCH PATIENT,
ANALYZING.
! NO TREATMENT ADVISED
(or NO SHOCK ADVISED)
These three prompts are optional:
— OPEN AIRWAY
— CHECK BREATHING
— GIVE TWO BREATHS
! CHECK CIRCULATION
(or CHECK PULSE)
! IF NO CIRCULATION START CPR
(or IF NO PULSE START CPR)
!!
2.6 Lift the puck that is attached to the
universal adapter cable. Move the
puck up and down very slightly
(no more than 1 inch or 2 cm) and
continue to do so.
If the unit has a display, prevent
the bar on the chest compression
gauge from extending into the
area between the lower two lines.
• Unit emits spaced tones as a guide
for performing chest compressions
at the proper rate.
! PUSH HARDER
!!
2.7 Increase the vertical motion of the
puck (about 2 to 3 inches or 5 to
8 cm).
If the unit has a display, make
sure the bar on the chest
compression gauge extends into
the area between the lower two
lines.
• Unit emits spaced tones as a guide
for performing chest compressions
at the proper rate.
! GOOD COMPRESSIONS
The following prompt is optional:
— IF NO CIRCULATION CONTINUE
CPR
(or IF NO PULSE CONTINUE
CPR)
! STOP CPR
!!
Test Action Expected Result(s) Pass Fail
