Specifications
Mono (MIC/GUITAR) 1Number of input
channels
Stereo (LINE IN) 1
Stereo (TRS) 1
Input and output channels
Number of output
channels
Stereo (PHONES) 1
Type XLR/TRS combo jack
(XLR: 2 HOT, TRS: TIP HOT)
Input gain +8 - +54 dB (MIC) / +8 - +54 dB
(GUITAR)
Input impedance XLR: 2 kΩ (MIC)
TS: 1 MΩ (GUITAR)
Maximum input level XLR: +0.6 dBu (MIC)
TS: +11 dBu (GUITAR)
MIC/GUITAR
Phantom power +48 V
Type TRS phone jacks (impedance
balanced)
Maximum output
level
−2 dBu (at 0 dBFS)
OUTPUT
(standard phone jacks)
Output impedance 100 Ω
Type 3.5mm stereo mini jack
20 mW + 20 mW (32 Ω load)
OUTPUT
(headphone jack)
Output impedance 10 Ω
USB USB Type-C (audio interface
function)
• Use a USB cable that supports
data transfer. USB bus power is
supported.
DC 5V USB Type-C (for power supply)
Type 3.5mm stereo mini jack
Input impedance 20 kΩ
Connectors
LINE IN
Maximum input level +1.5 dBu
Frequency response 44.1 kHz: +0/−2 dB (20 Hz – 20 kHz)
96 kHz: +0/−3 dB (20 Hz – 40 kHz)
Equivalent input noise –120 dBu or less (IHF-A) at
+54dB/150Ω input
Audio interface Input and output
channels
Recording: 2 channels
Playback: 2 channels
