Zoom B1Xon - Rear Panel Connections; Input and Output Jacks

5
Rear Panel O
Bass amplifier
Headphones
Portable audio
player, etc.
ZOOM AC
adapter (AD-16)
Computer
Bass guitar
INPUT jack
Pedal switch
( only)
OUTPUT jackAUX IN jack
USB
connector
DC9V
AC adapter jack
NOTE
Signals input through t
the AUX IN jack are
sent directly to the
OUTPUT jack without
passing through the
built-in effects.
