Connecting input and output devices
Wireless
mic
Shotgun
mic
When disconnecting a mic,
pull the XLR plug while
pushing the connector lock
release button.
Wireless
mic
Adjust the headphone
volume.
Headphones
Camera
Making input and recording settings
■
Home Screen overview
The waveforms and settings for each input are shown on the left and right of the screen.
Waveform display
(Input 1)
Input 1 settings
Waveform display
(Input 2)
Input 2 settings
