Zoom G1Xon User Manual

4 54 5
DYNAMICS / FILTER
AutoWah This effect varies wah in accordance with picking intensity.
Parameter1 Parameter2 Parameter3
Page01
Sense
-10–-1, 1–10 P Reso 0–10 P Level 0–150 P
Adjusts the sensitivity of the effect.
Adjusts the intensity of the resonance
sound.
Adjusts the output level.
Page02
Cry This effect varies the sound like a talking modulator.
Parameter1 Parameter2 Parameter3
Page01
Range 1–10 P Reso 0–10 P Sense
-10–-1, 1–10 P
Adjusts the frequency range processed
by the effect.
Adjusts the intensity of the resonance
sound.
Adjusts the sensitivity of the effect.
Page02
Bal 0–100 P Level 0–150 P
Adjusts the balance between original
and effect sounds.
Adjusts the output level.
M-Filter This envelope filter has the flavor of a MOOG MF-101 Low Pass Filter and can be set in a wide range.
Parameter1 Parameter2 Parameter3
Page01
Freq 0–100 P Sense 0–10 Reso 0–10 P
Sets minimum frequency of envelope
filter.
Sets effect sensitivity.
Adjusts the intensity of the resonance
sound.
Page02
Type
HPF, BPF, LPF Chara 2Pole, 4Pole VLCTY Fast, Slow
Sets filter type. Adjusts amount of filter applied. Sets speed of filter action.
Page03
Bal 0–100 P Level
0–150 P
Adjusts the balance between original
and effect sounds.
Adjusts the output level.
SeqFLTR The sequence filter has the flavor of a Z.Vex Seek-Wah.
Parameter1 Parameter2 Parameter3
Page01
Step 2–8 PTTRN 1–8 Speed 1–50 P
Adjusts number of sequence steps. Sets effect pattern. Sets modulation speed.
Page02
Shape 0–10 Reso 0–10 P Level 0–150 P
Sets effect sound envelope.
Adjusts the intensity of the resonance
sound.
Adjusts the output level.

Zoom G1Xon Specifications

General

Simultaneous Effects	5
Patch Memory	100
Looper	30 seconds
Rhythm Patterns	68
Display	LCD
Amp Models	22
Expression Pedal	Yes
USB	Yes
Power	AC adapter or 4 AA batteries
Inputs	1 x 1/4"
Outputs	1 x 1/4", 1 x 1/8" headphone
Effect Types	100+
