ZOOM GFX-1
Controls and Functions / Connections
[DC IN] (AC adapter) jack
The dedicated AC adapter AD-0006 (9 V DC, 300 mA,
center minus) can be connected here.
[POWER ON/OFF] switch
Serves to turn the GFX-1 on and off.
[CONTROL IN] jack
An optional expression pedal (FP01/FP02) can be connected here.
[CONTROL IN]
By connecting an optional
expression pedal (FP01/FP02) here,
you can adjust the effect intensity.
To guard against inadvertently disconnecting the AC
adapter cable, wind the cable around the hook, as
shown in the illustration.
