Zoom R4 User Manual

8
Adjusting the mix and bouncing
Adjusting the mix
■
Adjust EQ and panning
Press to return to the Home Screen.
Item Explanation
High This boosts or cuts high frequencies.
Middle This boosts or cuts mid-range frequencies.
Low This boosts or cuts low frequencies.
Pan This sets the left-right sound position.
Echo This adjusts echoes.
Reverb This adjusts reverberations and reections.
■
Use faders to adjust track levels
While listening to playback, use the faders to
adjust the balance.
1 2 3 4
－A － －
1 2 3 4

Zoom R4 Specifications

General

Type	Multitrack Recorder
Maximum Simultaneous Recording Tracks	4
Inputs	4 x XLR/TRS combo jacks
Phantom Power	+48V (Inputs 1-2)
Sampling Frequency	44.1 kHz
Bit Depth	24-bit
Power	USB power
Effects	compressor, EQ, reverb, delay
