Chapter 3: Status Monitoring 9
2 Connect one end of the supplied Ethernet cable to the
computer’s Ethernet port and the other end to your modem’s
Ethernet port. If you choose to use a USB cable instead,
connect one end of a USB cable to the computer’s USB port
and the other end to your modem’s USB port.
Back Panel Diagram
LINE ETHERNET RESET USB POWER
Note: The USB port is for X4 modems only.
3 Connect the supplied phone cord between your modem’s
LINE jack and a phone jack with ADSL service.
4 Plug the supplied power cube into the X3 or X4 modem, and
then into a power outlet.
Important: Use only the power cube shipped with your X3 or
X4 modem. Other power cubes may damage the device.
The POWER LED on the modem’s top panel should turn on.
5 Turn on the computer. The ETHERNET LED on your
modem’s top panel should turn on if you are using the
Ethernet port. After a few seconds, your ADSL LINE LED
will begin blinking, then become solid. If it does not become
solid, please refer to Appendix D: Troubleshooting.
For Windows XP users only: If a Found New Hardware Wizard
dialog opens and asks if you want to do a search for the
drivers, select No, not this time, then click Next. When the
Found New Hardware Wizard dialog reopens, select Install
the software automatically and click Next. If a Windows
logo testing disclaimer appears, click Continue Anyway. Click
Finish to close the application.
For Windows 2000 users only: If a Digital Signature Not Found
dialog appears, click Yes. Then click Finish.
