RT60 Rough Terrain Crane 01 - 1
1.1 HOIST TACKLE CHART
This chart only represents the maximum permissible hoist line load per parts of line. You
must refer to the proper Lift Charts for machine rated loads.
Table 01 – 1 Line Parts
MAXIMUM PERMISSIBLE HOIST LINE LOAD
LINE PARTS
1 2 3 4 5 6 7 8 9 10
MAXIMUM
PERMISSIBLE
HOIST LINE
LOAD (KG)
6000 12000 18000 24000 30000 36000 42000 48000 54000 60000
MAXIMUM
PERMISSIBLE
HOIST LINE
LOAD (LBS)
13230 26455 39680 52910 66140 79365 92595 105820 119050 132280
Wire rope: 19NAT-15*K7-IWRC-1960 MPa （3/4″ROTATION RESISTANT 15×K7 COMPACTED
STRAND, GRADE 1960）
Weight: 173 Kg/100m (1.16LBS/FT) Minimum breaking strength: 31.1T (30.61TONS)
1.2 TIRE INFLATION CHART
Table 01 – 2 Tire Inflation Chart
RECOMMENDED TIRE PRESSURE
TIRE SIZE STATIONARY
CREEP 1.6 Km/h（1 MPH）
TRAVEL
26.50-25-32PR
580 kpa（85 PSI） 580 kpa（85 PSI） 450 kpa（65 PSI）
