Maintenance Manual for Crawler Crane
4.17.3.8 Winch support
Figure 4-77 Winch support
4.17.4 Inspection of counterweight
4.17.4.1 Counterweight base plate
Inspect the welding seams at positioning blocks to ensure the counterweight plate can be
positioned reliably.
Figure 4-78 Counterweight base plate
4-95
