Zoomlion ZCC2600 User Manual

Maintenance Manual for Crawler Crane
Appendix
7.3 Attached tools
Table 7-4 Attached tools for ZCC1300 crawler crane
No.
ID code
Names of the tools
Quantity
Specification
1 1140102828 Pressure testing joint 1
2 1140102829 Pressure testing joint 1
3
1140207054
Testing hose
2
4
1140102826
Pressure testing joint
1
5 1140102830 Pressure testing joint 1
6 1140102954 Pressure testing joint 2
7
1019900189
Pressure gauge
2
8
1019900187
Pressure gauge
1
9 1991100004 Tool box assy. 1
10 1102000012 Wrench 1 Ф60-Ф140
11
1090100014
Flexible strap
2
12
1102900000
Screw jack
2
Table 7-5 Attached tools for ZCC1800 crawler crane
No. ID code Names of the tools Quantity Specification
1 1140102828 Pressure testing joint 1
2 1140207054 Testing hose 2
3 1140102826 Pressure testing joint 2
4 1140102830 Pressure testing joint 2
5 1140102954 Pressure testing joint 2
6 1019900189 Pressure gauge 2
7 1019900187 Pressure gauge 1
8 1991100004 Tool box assy. 1
9 1090100015 Wire rope 4 Ф26
10 1090100016 Arch shackle 2 1-3/4
11 1090100014 Flexible strap 2 5T-10000
12 1102900000 Screw jack 2
13 1019900014 Nitrogen filling tool 1
14 1140102831 Pressure testing joint 2
15 1140102832 Pressure testing joint 2
16 1019900048 Pressure testing joint 1
